Fiberglass Fish Tape Reel Duct Rodder with Cage and Wheel Stand S615870
Fiberglass Fish Tape Reel Duct Rodder with Cage and Wheel Stand S615870
Fish Tape Fiberglass Product Specifications: 6mm (1/4inch) Length: 130 M (425ft)
High Quality Material: Fiberglass and polyethylene plastics have good aging resistance and are not easy to break.
Abrasive wheel:Glass rubber wear-resisting roller, easy to implement, durable wear-resisting, long service life.
Feature:The rodder puller has the advantages of time saving, labor saving, improved work efficiency, etc.
Note:The maximum straight-line traction of the rodder puller is 2.5 tons. It is not allowed to use high-power machinery for traction in the 90-degree right-angle environment, otherwise it may break.
Features:
Glass fiber: Fiberglass Wire Cable is an excellent assistant tool for traction and guide line in pipeline. Smooth and flexible surface can make the perforated device easily through the narrow channel.
Quality steel: strong and durable, non conductive, anti rust and anti-corrosion, excellent tensile strength.
Widely use: electrical, wall and floor conduit, walker duct and utility installations.
How to use:
1. The overlaying rod is led out by the lead wheel and then connected with the corresponding metal head into the pipeline.
2. When used to clean up, the guide head drives the cleaning tool to clean the pipe.
3. When the cable is used, steel wire or iron wire can be brought in, and then the wire or iron wire can be used to pull the cable into the pipe.
Specification:
Diameter: 6 mm
Length: 130 Meters
Color: Yellow
Min Bend Radius: 295 mm(12'')
Breaking Tension: 4.5 T
Work situation temperature: -40~+80℃
Epoxy fiberglass (inner) and high density polyethylene (outer)
Used in the telecommunications industry, electrical, wall and floor conduit, walker duct and utility installations.
